DMO600 Digital Micro-Ohmmeter
600 A DC micro-ohmmeter for high-current contact-resistance testing where 200 A is not enough to seat the measurement.
Extends the DMO family to 600 A DC for large breaker contacts, generator connections and heavy busbar joints where higher test current gives a more representative resistance figure.
Automatic range selection with simultaneous current, voltage and resistance display, and results storage to USB for commissioning records.
Availability
Backordered — sourced independently
Not on our shelf today. Z Power Electric sources this part through independent, surplus, and new-old-stock channels rather than waiting on the factory queue, and confirms price and lead time within 24 hours.
Catalog pricing
Request pricing and availability for this item. Z Power Electric can confirm lead time, sourcing options, and part details.
- 30-day returnsOn standard orders
- 24-hour quoteFrom our sourcing team
Quick facts
- Brand
- T&R Test Equipment
- Part number
- DMO600
- Category
- Sensors & Instrumentation
Downloadables
Product overview
Supplied with a standard lead set; 3 m, 5 m and 10 m extension sets are available separately for joints away from the instrument position.
Specifications
- Part Number
- DMO600
- Brand
- T&R Test Equipment
- Metal Case Weight
- 15.8 kg
- Metal Case Dimensions
- 380 x 314 x 221 mm
- Pelican Case Weight
- 19.7 kg
- Pelican Case Dimensions
- 560 × 456 × 265 mm
- Supplied Accessories
- User manual Calibration certificate Mains lead 3m Output lead set Orange carry case for metal case version Earth lead with croc clip USB key USB keyboard
Key features
- Ultra lightweight (19.7g)
- 10-600A DC test current with <2.5% ripple
- 0.1μΩ resolution
- mV, A, and m/μΩ displayed simultaneously
- USB memory key for data storage
- USB keyboard for comment entry
- Pre-settable test current with three buttons to store user test currents
- Large back-lit liquid crystal display
- Universal supply voltage 90-264V
- Supplied with 3m output lead set
- Optional current clamp to allows testing of objects with both sides earthed
