NLU2000 Loading Unit

Name: NLU2000 Loading Unit
Brand: T&R Test Equipment
SKU: NLU2000
Availability: LimitedAvailability

2000 A loading unit for primary injection testing at currents beyond the range of the NLU200.

Presents a controlled load at up to 2000 A for primary current injection work on larger switchgear and CT circuits.

Pairs with NAL2000 output leads, available in 1.5 m, 3 m and 5 m lengths depending on how far the loading unit sits from the test set.

Catalog pricing

Request quotePricing confirmed by sourcing

Request quote

Request pricing and availability for this item. Z Power Electric can confirm lead time, sourcing options, and part details.

Talk to a sourcing expert

Mon - Fri 9:00 AM - 4:30 PM PST

Sat - Sun Closed

Intended for commissioning teams proving protection on medium and high current primary circuits.

Part Number: NLU2000
Brand: T&R Test Equipment
Weight: 50 kg
Dimensions: 450 × 275 × 305 mm
Supplied Accessories: User manual Calibration certificate Output screw set 2 x 19mm ring combi spanner

Exceptional versatility and reliability
Three output taps for a wide range of load impedances
Configurable maximum current: 2000A on the 4V range, 1000A on the 8V range or 500A on the 16V range
Seamless connection to the Control Unit with included interconnect lead
Designed to meet the stringent requirements of BS EN61010
Duty cycle trip and thermal protection for enhanced safety
